反射激光式超声测厚传感器及其应用

基金项目:

国家自然科学基金;江苏省自然科学基金;教育部高校优秀青年教师奖励计划;激光技术国家重点实验室开放基金资助项目

详细信息

Reflected laser ultrasonic sensor for testing thickness and its application

Department of Applied Physics, Nanjing University of Science & Technology, Nanjing, 210094

摘要: 研制了激光超声测厚传感器,并对其测试原理进行了讨论.该传感器具有高频响、频带宽、较高的灵敏度且易于调节.进而采用该传感器测试了由脉冲Nd:YAG激光在抛光的薄铁片上所激发的超声纵波.根据铁片背面对心处接收到的超声纵波及其回波波形,可以推算出样品薄板的厚度.理论和实验测试结果显示,该传感器的相对测量误差达0.5%.
- 激光超声 /
- 光偏转 /
- 测厚传感器 /
- 纵波
Abstract: A new laser ultrasonic sensor for testing samples' thickness is developed.The detection principle is discussed in detail.This sensor has high-frequency response,high sensitivity and is easy to adjust.The sensor is used to detect laser-induced ultrasonic longitude-wave at the epicenter of the rear metallic surface when pulse Nd:YAG laser is focused on polished iron plate.Well-defined longitude-wave and its echo waves are acquired.Based on the experimental results,the sample's thickness can be deduced.The theoretical and experimental results are in good agreement with relative error of 0.5%.
- laser ultrasound /
- optical beam deflection /
- senor for testing thickness /
- longitudinal wave

[1]	应崇福.超声学.北京:科学出版社,1993:103～112.
[2]	袁易全.超声换能器.南京:南京大学出版社,1989:130～191.
[3]	金长善.超声工程.哈尔滨:哈尔滨工业大学出版社,1989:189～205.
[4]	袁易全,陈思忠.近代超声原理与应用.南京:南京大学出版社,1996:353～354.
[5]	Aussel J D,Brun A L,Baboux J C.Ultrasonics,1988,26:245～255.
[6]	陆建,侯锐,陈建平 et al.第八届现代声学国际会议.北京:科学出版社,2001,11(S312):103～105.
