小型TEA CO2激光器的快速调谐技术研究

基金项目:

国家自然科学基金;黑龙江省自然科学基金资助项目

详细信息

Research of rapidly tuning technology of miniature TEA CO2 laser

National Key Laboratory of Tunable Laser Technology, Harbin Institute of Technology, Harbin, 150001

摘要: 报道了两种快速调谐技术的研究-6面转镜+固定光栅法和高频步进电机驱动光栅法.实验表明,高频步进电机法优于转镜法.实验得到激光器的一级调谐输出谱线50余条,激光输出能量(30～100)mJ.在单台CO2激光器上实现快速调谐输出波长不同的激光脉冲,其时间间隔达到≤10ms.
- CO2激光器 /
- 快速调谐 /
- 单片机 /
- 差分吸收雷达
Abstract: In this paper,two rapidly tuning techniques which include a six surface mirrors scanning a fixed grating and a high frequency stepping motor controlling a diffraction grating are presented.It is illustrated in experiments that the means of stepping motor is better than that of rotating mirror.Laser operated at 51 emission lines is obtained,and the pulse energy of laser radiation at first order is about (30～100)mJ.The system can be tuned rapidly different rotational lines with a single laser,the tuning time interval to different lines is not large than 10ms.
- CO2 laser /
- rapidly tuning /
- monolithic microprocessor /
- differential absorption lidar

[1]	Carlisle C B,van der Laan J E,Carr L W et al.Appl Opt,1995,34(27):6187～6200.
[2]	Faxvog F R,Mocker H W.Appl Opt,1982,21(22):3986～3987.
[3]	Crocker A,Jenkins R M,Johnson M.J Phys E:Sci Instrum,1985,18(1):133～135.
[4]	Fox J,Ahl J L.Appl Opt,1986,25(21):3830～3834.
[5]	Qu Y Ch,Hu X Y,Liu F M et al.Infrared Physics Technology,2000,41(3):143～147.
[6]	于志伟,曲彦臣,刘逢梅 et al.激光技术,2000,24(4):244～247.
[7]	Tan G R,Yang W X,Wang S J et al.Infrared Phys,1991,131(2):207～209.
[8]	Qu Y Ch,Liu F M,Hu X Y et al.Infrared Physics Technology,2000,41(3):139～142.
[9]	曲彦臣,胡孝勇,刘逢梅 et al.激光与红外,2000,30(3):160～163.
