模拟燃气射流场的莫尔偏折显示及定量测试

详细信息

Display and quantitative measurement of simulated exhaust flow field by Moir deflectometry

Dept. of Applied Physics, Nanjing University of Science & Technology, Nanjing, 210094

摘要: 在实验室条件下,制作了模拟膛口高速射流的装置.应用莫尔偏折法对双基发射药膛口燃气射流场进行了显示及定量测试研究.整套莫尔显示及测试系统由激光光源、莫尔偏折仪、CCD、监视器、图像存储和处理系统以及586计算机等组成.应用莫尔偏折层析技术定量计算并再现了膛口双基发射药燃气射流场的温度分布.
- 莫尔偏折法 /
- 双基发射药 /
- 膛口燃气射流场 /
- 层析
Abstract: A simulated set up of high-speed simulated exhaust muzzle flow field is made up.Moir deflectometry is used to display and quantitatively measure jet flow field of bi-based power muzzle.The system consists of laser source,Moir deflectometer,CCD,monitor,image store and processor and 586 computer.Using Moir deflectometry and tomography the distribution of temperature of flow field is visualized and calculated quantitatively.
- Moir deflectometry /
- bi-based power /
- exhaust flow field muzzle /
- tomography

[1]	Harsbger F.AD-44088,1964
[2]	Lian W Y,Zhang F X.The Structure and Properties of underexpanded Exhaust Jets.International Symposium on Defiend Flow Modelling and Turbulence Measurement,Iowa City,U S A.1985;A12:16～18
[3]	He A Zh,Yan D P.Opt Engng,1988;10(27):941～945
[4]	阎大鹏,王振东,刘峰et al．柴油内燃机流场的莫尔偏折显示及计算,第五届全国实验流体力学学术会议论文集,1996:314～318
[5]	Liu F,Wang Zh D,Yan D P et al.Visualization and analysis of gun muzzle temperature field by moire deflectometry.Heat Transfer Science and Technology,1996:224～228
[6]	Keren E,Bar-Zir E et al．Appl Opt,1981;20(12):4263～4266
[7]	Bar-Zir E,Sgnlion S,Kafri O．Appl Opt,1983;22(5):698～725
[8]	Roggemann M C,Welsh B M,Gardner P J et al．Opt Engng,1995;34(5):1374～1384
[9]	王振东.三维流场层析研究.南京理工大学学位论文,N960203,1996
