激光全息光栅计算机自动测试系统

详细信息

A microcomputer automatic measurement system for laser holographic optical grating

摘要: 本文介绍了激光全息光栅计算机自动测试系统结构、光学测量原理及对航空膜盒的测试,并对测试结果进行了讨论,系统已通过技术鉴定。
- 全息光栅 /
- 光学傅氏变换 /
- 二次衍射
Abstract: Aviation sylphone is a high precise element and widely employed in air,oil,chemistry and coal industry.Based on grating diffraction principle,we developed a microcomputer automatic measurement system for checking the displacement of aviation sylphone.The system utilizes a He Ne laser with 8mW power output as the light source to provide the 0.53μm resolution and ±0.8μm measurement accuracy.
- holographic optical grating /
- optical Fourier transformation /
- secondary diffraction
