Research of intensity noise suppression in laser diode pumped Nd:YAG lasers
-
摘要: 为了降低半导体抽运固体激光器的弛豫振荡噪声,提高其输出功率的稳定性,采用光电负反馈的方法来抑制半导体抽运的固体激光器的强度噪声,并对激光器强度噪声的理论特性进行了分析。根据理论分析结果设计了比例-积分-微分反馈控制电路,通过运用该反馈电路对激光器进行强度噪声抑制实验,得到了比较理想的实验数据,即当抽运功率为700mW、弛豫振荡峰频率为300kHz时,弛豫振荡峰值处和低频区域强度噪声分别降低了45dB和15dB;当抽运功率为550mW、弛豫振荡峰值为250kHz时,弛豫振荡峰值处和低频区域强度噪声分别降低了40dB和10dB。结果表明,该反馈控制电路能够有效地降低半导体抽运固体激光器的强度噪声,提高激光器输出功率的稳定性。Abstract: In order to reduce the relaxation oscillation noise of a diode pumped solid-state laser and improve its stability of output power, the intensity noise was suppressed by means of optoelectronic negative feedback. Theoretical characteristics of laser intensity noise were analyzed. According to the results of theoretical analysis, a proportion-integration-differention(PID) feedback control circuit was designed. By carrying out feedback circuit to suppress the laser intensity noise, ideal experimental data were obtained. When pumped power is 700mW, peak frequency of relaxation oscillation is 300kHz, intensity noise at relaxation oscillation peak and low frequency decreases to 45dB and 15dB respectively. When pumped power is 550mW, relaxation oscillation peak frequency is 250kHz, intensity noise at relaxation oscillation peak and low frequency decreases to 40dB and 10dB respectively. The results shows that the feedback control circuit can effectively reduce intensity noise of a diode pumped solid state laser and improve the stability of laser output power.
-
-
[1] YANG S T, IMAI Y, OKA M, et al. Frequency stability,10W continuous-wave,laser-diode end-pumped,injection-locked Nd:YAG laser[J]. Optics Letters,1996,21(20):1676-1679.
[2] FARINAS A D, GUSTAFSON E K, BYER R L.Frequency and intensity noise in an injection-locked solid-state laser[J].Journal of the Optical Society of America,1995,B12(2):328-334.
[3] HARB C C, BACHOR H A, SCHILLING R, et al. Suppression of the intensity noise in a diode-pumped Nd:YAG non-planar ring laser[J].IEEE Journal of Quantum Electronics,1994,30(12):2907-2913.
[4] ROWAN S,CAMPBELL A M,SKELDON K, et al. Broadband intensity stabilization of a diode-pumped monolithic miniature Nd:YAG ring laser[J].Journal of Modern Optics, 1994,41(6):1263-1269.
[5] WILLKE B, UEHARA N, GUSTAFSON E K, et al. Spatial and temporal filtering of a 10W Nd:YAG laser with a Fabry-Perot ring-cavity premode cleaner[J].Optics Letters, 1998,22(11):1704-1707.
[6] CHEN Y L,ZHANG J,LI Y M, et al. Reduction of intensity of single-frequency Nd:YVO4 laser using mode cleaner[J].Chinese Journal of Lasers,2001,28(3):197-200(in Chinese).
[7] ZHANG J,MA H L,WANG R L,et al.Suppression of intensity noise of LD-pumped single-frequency ring Nd:YVO4 laser by opto-electronic feedback[J].Acta Optica Sinica,2001,21(9):1031-1034(in Chinese).
[8] ZHAO Y,GAO C Q,CAO Y L,et al.Study on laser-diode-pumped 1319nm single frequency laser tuning and noise suppression[J].Laser Technology,2004,28(5):466-468(in Chinese).
[9] LI Y, CAO J P, DENG Y K, et al.Study on the properties and suppression of the intensity noise in semi-nonplanar monolithic lasers[J].Chinese Journal of Lasers,2005,32(8):1050-1054(in Chinese).
[10] LIANG X,WANG Y X,QIU Q,et al. Intensity noise properties and suppression of nonplanar ring oscillator[J]. Chinese Journal of Lasers,2012,39(12):6-10(in Chinese).
[11] REN C,ZHANG S L, Abnormal intensity noise of LD-pumped microchip Nd:YAG laser[J].Journal of Applied Optics,2012,33(3):609-613(in Chinese).
[12] CHEN M,WEI X Y,WU N L,et al.Theoretical research on relaxation oscillation in solid-state laser with relaxation oscillation pumping[J]. Chinese Journal of Quantum Electronics,2004,21(3):311-316(in Chinese).
[13] ZHOU B K.Laser principle[M].5th ed.Beijing:National Defense Industry Press,2008:6(in Chinese).
[14] GAO L,WANG J F,YANG S H,et al.Development of the LD-pumped monolithic Nd:YAG laser power supply[J]. Laser Technology,2006,30(6):664-666(in Chinese).
[15] ZHANG J,MA H L,WANG R L,et al. Intensity noise properties of LD pumped single-frequency ring lasers[J].Acta Optica Sinica,2000,20(10):1311-1316(in Chinese).
