Experimental study about generation of picosecond pulses with dual-wavelengths and tunable pulse-widths
-
摘要: 为了提高多波长光脉冲设备的实用性,采用双波长工作原理,设计了一种稳定的双波长半导体环形光纤激光器。讨论了环形腔色散、滤波器脉宽以及调制深度等对输出脉冲的影响。结果表明,双波长光脉冲的重复率为5.0GHz,典型脉宽为20ps,双波长光脉冲具有良好的边模抑制比,当输出波长为1554.75nm和1557.21nm时,边模抑制比分别为29.1dB和29.7dB,其典型的输出功率分别为-6.7dBm和-6.1dBm,输出光谱的峰值功率波动小于0.5dB。这项研究对太赫兹源和多波长光脉冲设备的研究具有借鉴意义。Abstract: In order to improve the practicability of multi-wavelength optical pulse equipment, a stable dual-wavelength semiconductor fiber ring laser was proposed and demonstrated by using dual-wavelength principle. Effects of ring cavity dispersion, filter pulse-width and modulation depth on output pulse were discussed. Experimental results are that repetition rate of dual-wavelength pulses is 5.0GHz and typical pulse-width is 20ps. Dual-wavelength pulses have good side-mode suppression ratios of 29.1dB (at 1554.75nm) and 29.7dB (at 1557.21nm) with typical output powers of -6.7dBm and -6.1dBm respectively. Output spectra are very stable with peak power fluctuation less than 0.5dB. This study is of great significance for the study of terahertz source and multi-wavelength optical pulse equipment.
-
Keywords:
- lasers /
- dual-wavelength /
- actively mode-locked /
- semiconductor optical amplifier
-
-
[1] ZHANG W W, SUN J Q, WANG J, et al. Optical clock division based on dual-wavelength mode-locked semiconductor fiber ring laser[J]. Optics Express, 2008,16(15):11231-11236.
[2] CHENL R, CSRTLEDGE J C. Mode-locking in a semiconductor fiber laser using cross-absorption modulation in an electro-absorption modulator and application to all-optical clock recovery[J]. Journal of Lightwave Technology, 2008, 26(7):799-806.
[3] VLACHOS K.Optical clock recovery and clock division at 20Gb/s using a tunable semiconductor fiber ring laser[J]. Optics Communications, 2003,222(1/6):249-255.
[4] TANG W W, FOK M, SHU C. 10GHz pulses generated across a~100nm tuning range using a gain-shifted mode-locked SOA ring laser[J]. Optics Express, 2006, 14(6):2158-2163.
[5] MA H Q, ZHAO W, ZHANG W, et al. Wavelength-tunable passively mode-locked fiber lasers[J]. Laser Technology, 2006, 30(3):289-291(in Chinese).
[6] YANG Sh Q, LI Zh H, DONG X Y, et al. Generation of wavelength-switched optical pulse from a fiber ring laser with an FP semiconductor modulator and a HiBi fiber loop mirror[J]. IEEE Photonics Technology Letters, 2002, 14(6):774-776.
[7] ZHAO Y, LIU Y Zh, ZHAO D Sh, et al. Evolution of mode-locked technology of fiber lasers[J]. Laser Technology, 2009, 33(2):162-165(in Chinese).
[8] LIN G R, LEE Ch K, KANG J J.Rational harmonic mode-locking pulse quality ofthe dark-optical-comb injected semiconductor optical amplifier fiber ring laser[J]. Optics Express, 2008, 16(12):9214-9221.
[9] YEH C H, SHIH F Y, CHEN C T, et al. Stabilized dual-wavelength erbium-doped dual-ring fiber laser[J]. Optics Express, 2007, 15(21):13844-13848.
[10] JUNG E J, KIM Ch S, HAN Y G, et al. Fast-interleaving of dual-wavelength fiber ring laser using switchable fiber Bragg gratings[J]. Optics Express, 2008, 16(4):2791-2796.
[11] CHEN Z, MA S, DUTTA N K. Multi-wavelength fiber ring laser based on a semiconductor and fiber gain medium[J]. Optics Express, 2009, 17(3):1234-1239.
[12] CAO H, CHEN L R. Wavelength tuning in optically mode-locked semiconductor fiber ring lasers with linearly chirped fiber Bragg gratings[J]. Applied Optics, 2005, 44(17):3545-3551.
[13] WEI X M, XU Sh H, HUANG H Ch, et al. Compact all-fiber ring femtosecond laser with high fundamental repetition rate[J]. Optics Express, 2012, 20(22):24607-24613.
[14] MANGENEY J, MERGAULT A, ZEROUNIAN N, et al. Continuous wave terahertz generation up to 2THz by photomixing on ion-irradiated InGaAs at 1550nm wavelengths[J]. Applied Physics Letters, 2007, 91(24):241102-241103.
[15] HE J Y, MIAO Q Y, HE J, et al. Generation of tunable dual wavelength optical short pulses for the generation and modulation of terahertz radiation[J]. Chinese Optics Letters,2011,9(s1):S102051-S102053.
[16] NAKAZAMA M, KUBOTA H, SAHARA A, et al. Time-domain ABCD matrix formalism for laser mode-locking and optical pulse transmission[J]. IEEE Journal of Quantum Electronics, 1998, 34(7):1075-1081.
[17] TOWN G E, CHEN L, SMITH P W E. Dual wavelength mode-locked fiber laser[J]. IEEE Photonics Technology Letters, 2000, 12(11):1459-1461.
[18] HE J, CHAN K. Wavelength-switchable all optical clock recovery at 10Gbit/s based on semiconductor fiber ring laser[J]. Optics Express, 2005, 13(1):327-335.
[19] HE J, CHAN K T. All-optical actively mode-locked fiber ring laser based on cross-gain modulation in SOA[J]. Electronics Letters, 2002, 38(24):1504-1505.
[20] YANG Sh Q, LI Zh H, YANG Sh Zh, et al. Tunable dual-wavelength actively mode-locked fiber laser with an FP semiconductor modulator[J]. IEEE Photonics Technology Letters,2002, 14(11):1494-1496.
-
