Precision analysis and post-processing application of a multi-axis laser strengthened machine
-
摘要: 为满足模具行业对激光强化设备的需求,研制了一台多轴激光强化机床。在普通三轴数控机床基体的基础上,对原机床主轴部位进行改进,加入两个旋转轴、激光器及CCD观察系统。采用激光干涉仪对机床运动轴的定位精度和重复定位精度进行测量和补偿,分析机床各运动轴的运动和激光加工的特点,结合UG NX后处理编辑工具对多轴激光强化机床的后处理进行了理论分析和实验验证。结果表明,补偿后机床的定位精度不大于0.05mm,重复定位精度为0.02mm。根据现有模具,运用研制的UG NX后处理进行编程,导入到机床中,实现了激光表面强化处理。这一结果证明了试验激光加工机床及后处理的可行性,对普通机床升级到激光加工设备是有帮助的。
-
关键词:
- 激光技术 /
- 激光强化机床 /
- UG NX后处理编辑工具 /
- 激光干涉仪 /
- 模具
Abstract: To meet requirements of laser strengthened machines for mould industry, a multi-axis laser machine was constructed. On the basis of ordinary three-axis computer numerical control machine tools, spindle part of the ordinary machine was improved by adding two rotary axes, a laser and a CCD observation system. Positioning accuracy and repeatable positioning accuracy of the machine motion axis was measured and compensated by a laser interferometer. Motion features of the machine and characteristics of laser processing were analyzed. Post-processing of the multi-axis laser strength machine was analyzed theoretically and verified experimentally by using UG NX post-processing editing tool. The results show that positioning accuracy of the machine is less than 0.05mm after compensation, repetition positioning accuracy is 0.02mm. Laser strengthening treatment achieves successfully by using UG NX post-processing editor on machine tool. Experimental results show the feasibility and versatility of a multi-axis laser machine and post-processing. It is helpful for the upgrade from ordinary machine tool to laser processing equipment. -
-
[1] SHI H L, LI J Q, JIA Zh X, et al. Microstructure and properties of SKD61 die steel strengthened by biomimetic laser-remelting[J]. Material for Mechanical Engineering, 2014,38(8):39-43(in Chin-ese).
[2] SALAS O, KEAMS K, CARRERA S, et al. Tribological behavior of candidate coatings for Al die casting dies[J]. Surface Coatings Technology,2003,172(2/3):117-127.
[3] ZHANG Ch H, LI Ch Y, ZHANG S, et al. Microstructure and property of laser surface melt-solidifying for H13 die steel[J]. Heat Treatment of Metals,2004,29(10):14-17(in Chinese).
[4] LIANG H, MA F R, ZHANG T H, et al. Surface structure and corrosion properties of binary Ti-C and Mo-C coatings Co-deposited by filtered vacuum arc plasma deposition system[J]. Surface Coatings Technology,2000,131(1/3):58-61.
[5] DENG M, WANG Y Q, GU Y, et al. Microstructure and wear behavior of laser hardened gray cast Iron guideway[J]. Chinese Journal of Lasers,2014,41(4):0403009(in Chinese).
[6] LIU L J, JIANG Y Q, DI T N, et al. HHT analysis of acoustic signal characteristics caused by defocusing amount fluctuation on laser strengthened mould surface[J]. Transactions of the China Welding Institution, 2013, 34(9):51-54(in Chinese).
[7] ZHANG M. The geometric error detection and distinguishing of laser interferometer based NC machine tool[J]. Mechanical Engineer,2006(9):76-78(in Chinese).
[8] ZHU J, LI X F, TAN W B, et al. Method of geometric error detection for measuring machine based on laser interferometer[J]. Journal of Mechanical Engineering,2010,46(10):25-30(in Chinese).
[9] LI R G. Calibration of tool spindle for 5-axis CNC machine using laser tracker[J]. Optics and Precision Engineering, 2012, 20(3):477-483(in Chinese).
[10] LIU Y Q, CAO Y H, PAN F, et al. Beam transformation of diode lasers used in laser processing[J]. Optics and Precision Engineering,2012,20(3):455-461(in Chinese).
[11] GAO P D, ZHANG F Q. Design and implementation of high precision temperature control system for semiconductor lasers[J]. Laser Technology,2014,38(2):270-273(in Chinese).
[12] SONG W X, ZHANG J Q, LIU X L. Development of post processing for five-axis CNC machine tools based on UG NX[J]. Manufacturing Technology Machine Tool, 2013(12):147-150(in Chinese).
[13] SHEN N Y, YU Zh X, LI J. Realization of the postprocessor of intelligent turning-milling combined machining cell based on UG NX[C]//4th International Conference on Manufacturing Science and Engineering.Geneva, Swiss:Advanced Material Research Society, 2013:2303-2307.
[14] TANG Q Ch, HE J, GAO L L, et al. The research of nonlinearity error control on five-axis machining post processor[C]//International Conference on Advance Design and Manufacturing Engineering. Geneva, Swiss:Advanced Material Research Society, 2011:2353-2357.
[15] GAO J, CHEN Y P, DENG H X, et al. In-situ inspection error compensation for machining accuracy improvement of complex components[J]. Journal of Mechanical Engineering,2013,49(19):133-142(in Chinese).
[16] LIU Y, XIE F, LIU J, et al. The NC machining post-processing technology based on UG[C]//3rd International Conference on Advance Engineering Material and Technology. Geneva, Swiss:Advanced Material Research Society,2013:1254-1257.
