Design of fiber acoustic sensors based on 33 coupler phase demodulation
-
摘要: 为了在某些应急情况下无源传输声音信号,采用基于光纤迈克尔逊干涉仪原理光纤声音传感的方法结合了收音弹性盘片和光纤粘接的工艺设计,使用33耦合器相位解调方法对传感信号进行相位解调,实现了一种新型光纤声音传感器系统。给出了干涉仪3路输出信号相位差的表达式,利用最小二乘法拟合求出干涉仪3路输出信号的平均相位差,取得了仿真与实际测试数据。经过测试,该系统可以准确有效地还原出设计带宽内的声音信号。结果表明,该光纤声音传感器系统适用于电磁恶劣等应急环境中,验证了该设计方案的可行性。Abstract: In order to transport acoustic signal passively in some emergent cases, a fiber acoustic sensor was designed based on the principle of an optical fiber Michelson interferometer, processing techniques of elastic discs and optical fiber adhesion, 33 coupler phase demodulation. The expressions of three phase differences of output signals were presented, and the average phase differences were calculated based on the least square method. Simulation data and test data were acquired. Experimental results demonstrate that a fiber acoustic sensor can restore acoustic signal accurately and effectively within designed bandwidth. A fiber acoustic sensor can be used in emergent environments such as severe electro-magnetic situation. The test results verify the feasibility of a fiber acoustic sensor.
-
Keywords:
- sensor technique /
- 3 /
- 3 coupler /
- phase difference /
- demodulation /
- fiber /
- acoustic sensor
-
-
[1] BUBEL G M, KRAUSE J, BICKTA B J, et al. Mechanical reliability of metallized optical fiberfor hermetic terminations[J].Journal of Lightwave Technology,1989,7(10):1488-1493.
[2] TAN J R, LIU Y Z, HUANG L.Development of fiberoptic gyroscope[J].Laser Technology,2006,30(5):544-547(in Chinese).
[3] KOOK P, TVETEN A B. Passive stabilization scheme for fiber interferometers using 33 fiber directional couplers[J].Applied Physics Letters,1982,41(7):616-618.
[4] REN G, JIANG Sh, YAN Q Zh, et al. Location technology of fiber intrusion detection system based on Fox-Smith interferometer with 33 coupler[J].Laser Technology,2014,38(4):480-483(in Chinese).
[5] ZHANG X, KANG C, SUN J H. Demodulation method based on the 33 optical fiber coupler[J]. Chinese Journal of Luminescence,2013,34(5):665-671(in Chinese).
[6] WANG Y J, LI F, XIAO H, et al. Sensitivity calculation of disk-type fiber-optic sensor[J].Acta Optica Sinica,2007,27(8):1387-1392(in Chinese).
[7] WANG Y J, LI F, XIAO H, et al. Fiber optic sound sensor based on michelson interferometer[J].Acta Photonica Sinica,2009,38(5):1114-1117(in Chinese).
[8] WANG Y, WANG Z P, SUN S, et al. Effect of temperature characteristic of Faraday rotator onpassively demodulated all-optical fiber current transformers[J].Power System Technology,2013,37(1):206-210(in Chinese).
[9] TAN J, CHEN W M, FU Y M. Application of Jones matrix in the research of polarization effects of thedistributed optic fiber sensor[J].Opto-Electronic Engineering, 2007,34(2):120-125(in Chinese).
[10] WANG J F, WANG X, LUO H. Influence of rotation angle and working wavelengths of Faraday rotation mirror on single-mode fiber optics michelson interferometer[J].Chinese Journal of Lasers,2010,37(4):1043-1046(in Chinese).
[11] WANG R, HAO X J, ZHOU H Ch, et al. Design of infrared signal detection circuit in a temperature calibration system[J].Laser Technology,2013,37(2):247-250(in Chinese).
[12] HE Y, LIU D M, SUN Q Z. Phase demodulation method of optic fiber sensor based on LabVIEW[J].Journal of Xinyang Normal University,2006,19(1):94-97(in Chinese).
[13] CHEN D S, XIAO L, CUI J, et al. Analysis of 33 coupler demodulation method for optical fiber interferometer and polarization fading[J].Journal of OptoelectronicsLaser,2007,18(5):523-525(in Chinese).
[14] HE J, XIAO H, FENG L, et al. Analysis of phase characteristics of fiber michelson interferometer based on a 33 coupler[J].Acta Optica Sinica,2008,28(10):1868-1873(in Chinese).
[15] WANG X, ZHANG Y, MA J, et al. Three road output demodulation simulation of fiber optical hydrophone[J].Ship Electronic Engineering, 2009,29(3):75-78(in Chinese).
