Research of deposition characteristics of Cr atoms in laser standing wave field with straight edge diffraction
-
摘要: 为了研究沉积基片对激光驻波场的影响,基于半经典理论,采用4阶龙格-库塔算法对直边衍射效应影响下铬原子的3维运动轨迹和3维沉积条纹结构进行了仿真。研究了激光束腰中心到反射镜的距离、高斯激光束腰半径对最终沉积过程的影响。结果表明,通过适当地调节实验参量,可以改变激光驻波场受到衍射效应的程度;当反射镜位于激光束腰截面处、高斯激光束腰半径为62.5μm时,纳米沉积条纹的质量最理想。这将为原子光刻实验提供有益的理论依据和数据信息。Abstract: In order to study the diffraction effect of deposition substrate on laser standing wave field, 3-D motion trail and stripe structure were simulated using the fourth-order Runge-Kutta algorithm under straight edge diffraction effect based on the semi-classical theory. The distance from laser beam waist center to mirror and the effect of the radius of Gaussian laser beam waist on the process of final deposition were discussed. The results show that diffractive degree will be changed by adjusting the experiment parameters reasonably. The quality of deposition stripe structure will be achieved optimally when the mirror is placed on the cross section of laser beam waist, and the radius of Gaussian laser beam waist equals 62.5μm. It provides the useful theoretical foundation and data information in the field of atomic lithography study.
-
Keywords:
- laser optics /
- diffraction effect /
- Runge-Kutta algorithm /
- Gaussian beam
-
-
[1] SHI C Y, QIAN J, TAN H P, et al. Results from national institute of metrology in NANO5 2-D grating comparison[J]. Laser & Optoelectronics Progress,2010(4):1-5(in Chinese).
[2] ZHANG B W, ZHI L X, ZHANG W T. Simulation of optical potential of Gaussian laser standing wave by diffraction of straight edge[J]. Acta Physica Sinica,2012,61(18):183201(in Chinese).
[3] ZHANG W T, LI T B. Atom lithography with a chromium atomic beam[J]. Chinese Physics Letters,2006,23(11):2952-2955(in Chinese).
[4] KUMAR R, KAURA S K, SHARMA A K, et al. Knife-edge diffraction pattern as an interference phenomenon: an experimental reality[J]. Optics & Laser Technology,2007,39(2):256-261.
[5] TANTUSSI F, MANGASULI V, PORFIDO N, et al. Towards laser-manipulated deposition for atom-scale technologies[J]. Applied Surface Science,2009,255(24):9665-9670.
[6] NIKOLAI K, FERMÍN S G A,PEDRO C X, et al. Optical testing with a knife edge interferometer[J]. Journal of Physics: Conference Series,2011,274(1):012063.
[7] WANG J B, QIAN J, YIN C, et al. Method of identifying the relative position between standing wave of laser light and substrate in atom lithography[J]. Acta Physica Sinica,2012,61(19):190601(in Chinese).
[8] ZHANG B W, MA Y, ZHANG P P, et al. Simulation of Gaussian laser standing wave based on diffraction by straight edge[J]. Laser Technology,2012,36(6):810-813(in Chinese).
[9] ZHANG B W, MA Y, ZHANG P P, et al. Effects of substrate diffraction on evolution of the atom wave-packet probability density in the focused laser standing wave[J]. Acta Optica Sinica,2012,32(12):1-7(in Chinese).
[10] ZHANG B W, MA Y, LI T B, et al. Effect of laser power on one-dimensional deposition of chromium atomic beam[J]. Acta Optica Sinica,2009,29(2):421-424(in Chinese).
[11] ZHANG B W, ZHI L X, ZHANG W T, et al. Effect of atomic velocity at substrate diffraction on laser-focused Cr atom deposition[J]. Laser Technology,2013,37(4):421-424(in Chinese).
[12] ZHANG W T, ZHU B H. A novel method to realize the nanometer scale grid deposition[J]. Acta Physica Sinica,2010,59(8):5392-5396(in Chinese).
[13] McCLELLAND J J. Atom-optical properties of a standing-wave light field[J]. Journal of the Optical Society of America,1995,B12(10):1761-1768.
[14] ZHANG W T, ZHU B H, XIONG X M. Focusing characteristic of chromium atoms under elliptical standing wave[J]. Acta Physica Sinica,2009,58(12):8199-8204(in Chinese).
[15] HUANG J, ZHANG W T, ZHU B H, et al. Characteristics of deposition for neutral atoms in laser standing wave with different velocities[J]. Acta Physica Sinica,2011,60(6):063202(in Chinese).
-
