Optimization of linear passive terahertz isolator
-
摘要: 为了获得结构简单、无需外加低温和强磁场的太赫兹隔离器,采用3维时域有限差分法对1种硅基光子晶体异质结结构的太赫兹隔离器进行了理论优化分析。该隔离器结构简单,可常温工作,并且无需外加磁场。结果表明,其隔离特性与两种光子晶体的孔径有关,在孔径比例合适(在0.52THz的最优化孔径比R1/R2=0.49)的情况下可以实现25dB的最大隔离度。Abstract: In order to obtain terahertz isolators with simple structure and without the need of additional low temperatures and strong magnetic fields, a silicon-based photonic crystal heterostructure THz isolator was ananlyzed and optimized by using three-dimensional finite-difference time-domain method (3-D-FDTD). The isolator can work at room temperature, with simple structure and without external magnetic field. The results show that the isolation characteristics depends on the ratio of the pore size of both the photonic crystals. In the right ratio of the aperture (optimized aperture ratio R1/R2=0.49 at 0.52THz),maximum isolation of 25dB can be achieved.
-
Keywords:
- nonlinear optics /
- terahertz isolator /
- photonic crystal /
- hetero junction /
- negative refraction
-
-
[1] FEDERICI J , MOELLER L. Review of terahertz and subterahertz wireless communications[J]. Jounal of Appllied Physics, 2010, 107(11): 111101.
[2] WANG Z, FAN S. Magneto-optical defects in two-dimensional photonic crystals[J]. Appllied Physics, 2005, B81(2/3):369-375.
[3] SMIGAJ W, ROMERO-VIVAS J, GRALAK B, et al. Magneto-optical circulator designed for operation in a uniform external magnetic field[J]. Optics Letters, 2010, 35(4): 568-570.
[4] SHALABY M, PECCIANTI M, OZTURK Y, et al. A magnetic non-reciprocal isolator for broadband terahertz operation[J]. Nature Communications, 2013, 4: 1558.
[5] HU B, WANG Q J, ZHANG Y. Broadly tunable one-way terahertz plasmonic waveguide based on nonreciprocal surface magneto plasmons[J]. Optics Letters, 2012, 37(11): 1895-1897.
[6] FAN F, CHANG Sh J, GU W H, et al. Magnetically tunable terahertz isolator based on structured semiconductor magneto plasmonics[J]. IEEE Photonics Technology Letters, 2012, 24(22): 2080-2083.
[7] FAN F, CHANG Sh J, NIU Ch, et al. Magnetically tunable silicon-ferrite photonic crystals for terahertz circulator[J]. Optics Communications, 2012, 285(18): 3763-3769.
[8] LUO Ch Y, JOHNSON S G, JOANNOPOULOS J D. All-angle negative refraction without negative effective index[J]. Physical Review, 2002, B65(20): 201104.
[9] RUAN Zh Ch, QIU M, XIAO S Sh, et al. Coupling between plane waves and Bloch waves in photonic crystals with negative refraction[J]. Physical Review, 2005, B71(4): 045111.
[10] MARTINEZ A, MIGUEZ H, GRIOL A, et al. Experimental and theoretical analysis of the self-focusing of light by a photonic crystal lens [J]. Physical Review, 2004, B69(16): 165119.
-
