New universal laser scanning head detector
-
摘要: 为了克服封头在传统检测中存在样板测量尺寸单一、人工读数精度低、制板耗费资源等缺点，采用激光测距2维轮廓连续扫描方法，设计了一种适用于检测不同尺寸封头形状偏差的非接触式激光检测装置，介绍了激光扫描封头仪的工作原理、扫描方式、系统组成以及各系统具体设计方法，并对内径为800mm的封头进行了实验验证。结果表明，此激光扫描封头检测仪的理想精度可达1mm~2mm，可实现高精度、高效率、自动化检测。Abstract: In order to overcome the disadvantages of the traditional head detection, such as limited size of measuring models, low accuracy of artificial reading and resource cost of plate making, a non-contact laser detection device, suitable for shape deviation detection of the head in different sizes, was designed with laser scanning 2-D contour continuously. Work principle, scan mode, system components and specific design of each subsystem of the laser scanning head device were introduced. A head with inner diameter of 800mm was verified in experiment. The results show that the laser scanning head device can make the detection automatically with high-precision, high-efficiency. The ideal accuracy can reach 1mm~2mm.
-
Keywords:
- laser technique /
- shape deviation /
- head /
- detection
-
-
[1] CHINA NATIONAL STANDARDIZATION MANAGEMENT COMMITTEE.GB150-2011 Pressure vessels[S]. Beijing: Standards Press of China,2011:115-151(in Chinese).
[2] CHINA NATIONAL STANDARDIZATION MANAGEMENT COMMITTEE.GB/T25198-2010 Heads for pressure vessels[S]. Beijing: Standards Press of China, 2010:2-9(in Chinese).
[3] LIU Ch B, WANG X Y. Full model checking on forming elliptical head[J]. Petro-chemical Equipment, 2001, 30(5):88-89(in Chinese).
[4] ZHONG Sh Y, LI S Sh. Study of multi-pulsed laser ranging technology[J]. Laser & Infrared, 2006,36(6):797-799(in Chinese).
[5] YASHIRO S, TAKATSUBO J, MIYAUCHI H, et al. A novel technique for visualizing ultrasonic waves ingeneral solid media by pulsed lasers can[J]. Nondestructive Testing and Evaluation International,2008,41(2):137-144.
[6] ZHANG G Y, AN Zh Y, LI Ch Zh, et al. Automatic detection system of laser scanning size[J]. Journal of Test and Measurement Technique, 1995, 9(2):18-26(in Chinese).
[7] XIE Z X, WANG J G, JIN M. Study on a full field of view laser scanning system [J]. Machine Tools and Manufacture,2007,47(1):33-43(in Chinese).
[8] GUAN X H, ZHENG Y. Development of monitor and simulalor soflware of laser sensor for distance measurement based on VB [J]. Industrial Control Calculation, 2006,19(7):47-48(in Chinese).
[9] CHEN L Y, FAN Y Zh. The latest version of visual basic and RS-232 serial communication control[M]. Beijing: China Youth Press, 2001:45-51(in Chinese).
[10] WANG H X, WU Ch. 3-D laser scanning technology and error analysis in the application process[J]. Journal of Gansu Sciences, 2012,24(3):17-20(in Chinese).
[11] LIU H, ZHANG D Y, FENG J. Error analysis for data of terrestrial 3-D laser scanner[J].Journal of Water Resources and Architectural Engineering, 2012,10(4):38-41(in Chinese).
