Characteristics of Nd:Y3Al5O12 thin film prepared by electron beam evaporation deposition
-
摘要: 硅基光电集成技术是当代高速信息化的重要发展方向之一。为了研究制备在硅衬底上的新型发光材料,突破Nd:YAG固体激光工作物质主要是晶体、透明陶瓷等固体形态的限制,采用电子束蒸发沉积工艺,在硅(100)衬底上制备了Nd:YAG薄膜,并对Nd:YAG薄膜的表面形貌、晶体结构、光学特性进行了测试。X射线和扫描电子显微镜测试结果显示,Nd:YAG薄膜经1100℃真空高温退火处理1h后有效结晶,采用钛蓝宝石激光器输出808nm激光激发,液氮冷却的InGaAs阵列探测器室温下得到Nd:YAG薄膜的1064nm主荧光峰的荧光光谱。结果表明,采用电子束蒸发沉积和后续高温退火工艺可以在硅衬底上制备Nd:YAG晶体薄膜。Abstract: Si-based optoelectronic integration technology is one of the main study topics and development directions for the high-speed information.New Si-based luminescent materials were developed to break the limits of Nd:YAG solid laser material,which was confined by two main solid states:single crystal and transparent ceramics.Nd:YAG thin film was prepared on Si(100) substrates by electron beam evaporation deposition.The surface morphology,crystalline phase and optical properties of Nd:YAG thin film were characterized by X-ray diffraction,scanning electron microscopy and spectrophotometer.The crystallization of Nd:YAG thin film was improved after annealing at 1100℃ for 1h in the vacuum,photoluminescent spectra of Nd:YAG thin film were measured at room temperature,with 808nm radiation from a Ti:sapphire laser,and photoluminescent spectrum in the region of 1064nm peak was detected by a liquid nitrogen cooled InGaAs detector array.The results showed that Nd:YAG crystalline thin film was grown on Si substrates for the first time by means of electron beam evaporation deposition and subsequent high temperature annealing process.
-
Keywords:
- thin films /
- Nd:YAG /
- electron beam evaporation /
- photoluminescence
-
-
[1] LI X,LIU H,WANG J Y,et al.Progress in transparent polycrystalline aluminum-yttrium garnet laser ceramic[J].Journal of Chinese Ceramic Society,2004,32(4):485-489(in Chinese).
[1] SHI J L,FENG T.Inorganic optical transparent materials-transparent ceramics[M].Shanghai:Shanghai Popular Science Press,2008:60-72 (in Chinese).
[2] EAKINS D K,HELD M,NORTON M G,et al.A study of fracture and defects in single crystal YAG[J].Journal of Crystal Growth,2004,267 (3/4):502-509.
[3] MAO Y L,Q1U H W,XU J,et al.Spectra and laser characteristics of high-doped Nd:YAG laser crystals[J].Acta Optica Sinica,2001,21 (10):1264-1267 (in Chinese).
[4] YANG R,TAO Z L,QIN J.Phase composition and luminescence properties of neodymium-doped yttrium aluminum gsrnet (Nd:YAG)ceramic powders[J].Journal of Beijing University of Chemical.Technology,2009,36(4):54-59(in Chinese).
[5] SUAREZ M,FERNANDEZ J,MENENDEZ J L,et al.Hot isostatic pressing of optically active Nd:YAG powders doped by a colloidal processing route[J].Journal of the European Ceramic Society,2010,30(6):1489-1494.
[6] MA H X,LOU Q H,QI Y F,et al.Spectrum characteristics of the polycrystalline transparent ceramic[J].Laser Technology,2004,28(5):488-490(in Chinese).
[7] LUPEI V,LUPEI A,LKESUE A.Single crystal and transparent ceramic Nd-doped oxide laser materials:a comparative spectroscopic investigation[J].Journal of Alloys and Compounds,2004,380(1/2):61-70.
[8] FELDMAN R,GOLAN Y,BURSHTEIN Z,et al.Strengthening of poly-crystalline (ceramic) Nd:YAG elements for high-power laser applications[J].Optical Materials,2011,33(5):695-701.
[9] FIELD S J,HANNA D C,LARGE A C,et al.Low thteslold ionimplanted Nd:YAG channel waveguide laser[J].Electronics Letters,1991,27 (25):2375-2376.
[10] HANNA D C,LARGE A C,SHEPHERD D P,et al.Low threshold quasi-three-level 946nm laser operation of an epitaxially grown Nd:Y3Al5012 waveguide[J].Applied Physics Letters,1993,63(1):7-9.
[11] FERRAND B,PELENC D,CHARTIER I.Growth by LPE of Nd:YAG single crystal layers for waveguide laser applications[J].Journal of Crystal Growth,1993,128 (1/4):966-969.
[12] SUN Z H,YUAN D R,DUAN X L,et al.Preparation of YAG mateiials by sol-gel method[J].Journal of Chinese Ceramic Society,2004,32(4):59-62(in Chinese).
[13] WU Y C,PAROLA S,MARTY O,et al.Strucural characterizations and waveguiding properties of YAG thin films obtained by different solgel processes[J].Optical Materials,2005,27(9):1471-1479.
[14] EZAKI M,OBAPA M,KUMAGM H,et al.Characterization of Nd:Y3Al5O12 thin films gown on various substrates by pulsed laser deposition[J].Applied Physics Letters,1996,69(20):2977-2979.
[15] REMSA J,JELINEK M,KOCOUREK T,et al.Highly oriented crystalline Er:YAG and Er:YAP layers prepared by PLD and annealing[J].Applied Surface Science,2009,2.55(10):5292-5294.
[16] REN H,PANG Z H,ZEN Q.Preparation of Nd:YAG ceramics materials by vacuum electron beam sintering method[J].Mechanical & Electrical Engineering Technology,2011,40(11):46-48 (in Chinese).
[17] LI J,WU Y,PAN Y,et al.Solid-state-reaction fabrication and properties of high-doping Nd:YAG transparent laser ceramic[J].Journal of Chinese Ceramic Society,2007,35 (12):1600-1604(in Chinese).
[18] LI X X,LI J T,HU Z G,Preparation of poly crystalline Nd:YAG nanopowders used for sintering transparent laser ceramics via lowtemperature combustion method[J].Journal of the Chinese Rare Earth Society,2007,25(4):483-486 (in Chinese).
[19] LIU S H,LI C F.Photonics technology and application[M].Guangzhou:Guangdong Science and Technology Press,2006:121-124(in Chinese).
