基于激光调制技术的射击训练模拟系统

详细信息

Shooting training systems based on laser modulation technology

1.
Department of Control Engineering, Academy of Armored Force Engineering, Beijing 100072, China;
2.
Department of Arms Engineering, Academy of Armored Force Engineering, Beijing 100072, China

摘要: 为了设计贴近部队轻武器射击训练的模拟系统,基于激光调制技术,结合TSOP34838芯片作为光电接收器件设计了仿真靶。使用滤光薄膜解决普通激光器光斑过大的问题,通过阵列式多路信号检测的方法简化了系统硬件设计,实现了多路数据信号快速简单的采集,通过设置振动传感器识别脱靶情况并增加了模拟训练的逼真度。结果表明,该系统使用无线通信方式,具有操作简单、稳定性高、细节处理得当、实用性较强等优点。
- 激光技术 /
- 仿真靶 /
- 激光调制 /
- TSOP34838 /
- 阵列检测法
Abstract: In order to design a simulation system for shooting training of small arms,based on laser modulation technology,a simulation target was designed with TSOP34838 chip as optical receiving device.A filter membrane was used to solve the problem that ordinary laser spot is too large,the hardware was simplified with array multi-channel signals detection method,multi-channel data were collected quickly and easily.This system can identifying off-target situation,and increase the fidelity by setting the vibration sensor.The simulation system uses wireless communication,has advantages of simple operation,high stability,properly handling details and practicality.
- laser technique /
- simulation target /
- laser modulation /
- TSOP34838 /
- array detection method

[1]	SHANG B.The research and design of simulating system for shooting training[D].Dalian:Dalian Maritime University,2008:10-16(in Chinese).
[1]	LI G.Design of laser target practice for simulation training[D]. Chongqing:Chongqing University,2005:8-15(in Chinese).
[2]	HUANG J J,YU J H.Automatic liiflc shooting training system by stimulation of laser[J].Applied Laser,2001,33(2):41-42(in Chinese).
[3]	ZHAO M.Research of laser simulate target system[D].Nanchang:Nanchang University,2007:15-22(in Chinese).
[4]	CHUI Y H.Design and implementation of a simulative shooting raining system[J].Microcomputer Development,2003,13(4):20-22 (in Chinese).
[5]	ZHANG Y.Research on key technology of photoelectric automatic scoring system[D].Beijing:Academy of Armored Force Engineering,2011:10-16(in Chinese).
[6]	CAO Y,ZHANG Y,CHEN L,et al.Design of photoelectric detection circuit based on laser coding modulation[J].Journal of Sichuan Ordance,2010,32(12):103-106(in Chinese).
[7]	ZHANG Zh Q.A new design used in large area laser screen for gun of high firing frequency[J].Optical Technique,2009,35(3):464-466 (in Chinese).
[8]	ZHOU Zh L.Laser spot location in imaging laser detecting systems[J].Laser Technology,2008,32(3):248-251(in Chinese).
[9]	FU H L.Research of laser character on laser ranging on practical ranging.[D].Hefei:Academy of Postgraduate in Chinese Academy of Sciences,2003:7-15(in Chinese).
