Wavelength calibration for miniature fiber optical spectrometers
-
摘要: 为了提高光纤光谱仪的测量精度,采用标准汞氩灯谱线和最小二乘法的3阶线性拟合,取得了完整的波长定标方案。结果表明,算术平均误差小于0.167nm,标准差小于0.217nm,波长与像素的拟合相关程度较高;定标后波长不确定度优于0.11nm,误差小于0.15nm,波长重复性可达0.01nm。这一结果对提高光谱仪实际应用中的测量精度是非常有益的。Abstract: In order to improve the measurement accuracy of the miniature fiber spectrometer,a complete calibration scheme was obtained based on the standard emission spectrum of mercury and argon lamp and three-order linear fitting of the least squares.Calibration results show that the arithmetic mean error is less than 0.167nm,standard deviation is less than 0.217nm and the fitting related degree is high.Test results show that after calibration the wavelength uncertainty is better than the 0.11nm,the error is less than 0.15nm,and the wavelength repeatability can reach 0.01nm.This result is beneficial for improving the measurement precision of spectrometers in the practical applications.
-
Keywords:
- spectroscopy /
- wavelength calibration /
- the least squares /
- fiber spectrometer
-
-
[1] JU H,WU Y H.The state of the art of micro spectrometers[J].Optics Precision Engineering,2001,9(4):372-376(in Chinese).
[1] HU Y,RONG J.The development and expectation of CCD[J].Chinese Journal of Scientific Instrument,2005,26(8):718-720(in Chinese).
[2] ZHANG Y,ZHAO Y,WU X M,et al.Advancement on multi-spectrum detecting and laser multi-spectrum detecting mtechnology[J].Laser Technology,2007,31(2):187-191(in Chinese).
[3] ZHANG Zh W.Microminiature fiber optic spectroscopy[J].Life Science Instruments,2006,4(8):51-54(in Chinese).
[4] JIA H,YAO Y.Characteristics of typical optical systems with diffractive gratings of micro spectrometers and improvement of spectrometer's resolution[J].Spectroscopy and Spectral Analysis,2007,27(8):1653-1656(in Chinese).
[5] DONG Sh R,HOU L T.Fabrication and the spectrum property of Yb3+-doped silicate glass[J].Laser Technology,2010,34(2):236239(in Chinese).
[6] WANG W L,TAN T,WANG L,et al.Development of micro-spectrometer based on linear CCD clip[J].Journal of Atmospheric and Environmental Optics,2011,6(4):299-304(in Chinese).
[7] SHI J F,HUI M,WANG D Sh,et al.Micromation and applications of spectrometers[J].Optical Technique,2003,29(1):13-15(in Chinese).
[8] JIA H,LI F T.Analysis of factors affecting spectral radiance calibrationby applying a diffuse plane[J].Acta Optica Sinica,2004,24 (3):383-387(in Chinese).
[9] LI X,ZHANG G W,XUN L N,et al.Wavelength calibration of shortwave infrared flat spectroradiometer[J].Acta Optica Sinica, 2008,28(5):902-906(in Chinese).
[10] HOPKINSTON G R,GOODMAN T M,PRINCE S R,et al.A guide to the use and calibration of detector array equipment[M]. Washington DC,USA:Sira Technology Ltd.,2004:123-136.
[11] QIAO D E,GU Y H,XU X L,et al.Wavelength calibration algorithm in grating spectrometer[J].Acta Photonica Sinica,2009,38 (9):2283-2287(in Chinese).
[12] SHEN H Ch,PAN J G,FENG H J,et al.Calibration of the fast scan multichannel spectrometer[J].Optical Instruments,2006,28 (2):51-55(in Chinese).
[13] SHI H L,XIONG W,ZUO M M,et al.Study on calibration method of spatial heterodyne spectrometer[J].Spectroscopy and Spectral Analysis,2010,30(6):1683-1687(in Chinese).
[14] XIE Y Zh,ZHUANG S L,ZHANG B Zh.Rsearch on calibration of spectrometer based on linear CCD[J].Chinese Journal of Scientific Instrument,2011,32(3):546-550(in Chinese).
[15] XU Zh M,YU B X.Wavelength calibration for PC20002PC/104 spectrometer[J].Optics and Precision Engineering,2004,12(1):11-14(in Chinese).
[16] SANSONETTI C J,SALIT M L,READER J.Wavelengths of spectral lines in mercury pencil lamps[J].Applied Optics,1996,35 (1):74-77.
[17] ZHANG T Q,ZHENG Y M.Research on demarcating methods of spectrum by CCD[J].Optical Technique,2002,28(3):257-258 (in Chinese).
