Microstructure and electric conductivity of laser clad TiB2/Cu coating on pure copper
-
摘要: 为了满足电磁导轨的使用要求,采用激光熔覆技术在纯铜表面通过预置粉的方式制备了不同成分TiB2/Cu涂层,用光学显微镜、扫描电镜和X射线衍射分析了涂层的微观结构及相组成。涂层由Cu和TiB2两相组成,当TiB2的质量分数分别为0.02,0.05和0.1时,涂层的显微硬度分别约为95HV0.1,105HV0.1和152HV0.1,电导率为22.9MS/m,20.4MS/m和16.4MS/m。涂层与基体呈良好冶金结合,无裂纹在,TiB2颗粒存在团聚现象,熔覆层组织为外延生长的柱状晶。结果表明,随着TiB2的含量增大,涂层显微硬度升高,涂层的电导率下降。Abstract: In order to meet the requirement for electromagnetic rails,through presetting powder on pure copper surface,TiB2/Cu coatings with different proportion of TiB2 were prepared by means of laser cladding.The microstructure and phases were investigated with optical microscopy,scanning electron microscopy and X-ray diffraction.The coating composed of Cu and TiB2,when the mass fraction of TiB2 is 0.02,0.05 and 0.1,the micro-hardness of the coating is approximately 95HV0.1,105HV0.1and 152HV0.1,and the electrical conductivity is 22.9MS/m,20.4MS/m and 16.4MS/m respectively.The coating metallurgically bonded with the substrate,free of cracks,and some agglomerated TiB2 particles exist.The clad layer possesses the epitaxial growth of columnar crystal.The results show that with increase of TiB2 content,the micro-hardness of TiB2/Cu coatings increases,and the conductivity decreases.
-
Keywords:
- laser technique /
- electrical conductivity /
- laser cladding /
- TiB2/Cu coating
-
-
[1] PETERS D T.Copper alloys for industrial hardware[J].Advanced Materials and Processes,1996,150(4):30-32.
[1] ZHANG Y Z,TU Y,XI M Z,et al.Characterization on laser clad nickel based alloy coating on pure copper[J].Surface and Coatings Technology,2008,202(24):5924-5928.
[2] LIU J L.Development of surface treatment technologies of copper alloy[J].Nonferrous Metals Processing,2008,37(4):45-47(in Chinese).
[3] WANG H M,ZHANG L Y,LI A,et al.Progress on laser melting deposition process and manufacturing of advanced aeronautical metallic structural materials and coating[J].Heat Treatment of Metals,2008,33(1):82-85(in Chinese).
[4] YANG G R,HAO Y,SONG W M,et al.Surface composite on the substrate fabricated by infiltration casting[J].Acta Materiae Compositae Sinica,2005,22(1):52-57(in Chinese).
[5] JIAN Zh H,MA Zh,WANG F Ch,et al.Study on high velocity oxyfuel and plasma spraying process of W coatings on copper substrate[J].Ordnance Material Science and Engineering,2007,30(2):2730(in Chinese).
[6] ZHU C Y,LI G Q,ZHANG F,et al.Progress in study of surface treatment technology for continuous casting mould[J].Materials Protection,2005,38(5):43-47(in Chinese).
[7] ZHANG X Q,XU Z H,DENG J Q,et al.Preparation methods and techniques of Cu-based composite[J].Hot Working Technology,2007,36(6):73-77(in Chinese).
[8] LEE D W,KIM B K.Nanostructured Cu-Al2O3 composite produced by thermochemical process for electrode application[J].Materials Letters,2004,58(3/4):378-383.
[9] SUNDBERG G,PAUL P,SUNG C M,et al.Fabrication of Cu-SiC metal matrix composites[J].Journal of Materials Science,2006,41 (2):485-504.
[10] LIU D B,CUI C X.Fabrication and properties of TiN particle-reinforced copper matrix composites[J].Chinese Journal of Rare Metals,2004,28(5):856-861(in Chinese).
[11] TJONG S C,LAU K C.Abrasive wear behavior of TiB 2 particle-reinforced copper matrix composites[J].Materials Science and Engineering,2000,A282(1/2):183-186(in Chinese).
[12] DONG Sh J,LEI Y P,SHI Y W.In situ formation of titanium diboride/copper composite[J].Journal of Xi'an Jiaotong University,2000,34(5):69-73(in chinese).
[13] LEE J S,JUNG J Y,LEE E S,et al.Microstructure and properties of titanium boride dispersed Cu alloys fabricated by spray forming[J].Materials Science and Engineering,2000,A277(1/2):274283(in Chinese).
[14] CHEN Sh Ch,CHEN L B.Physical properties of material[M].Shanghai:Shanghai Jiaotong University Press,1999:56-60(in Chinese).
