Effect of assembling error in LD array on homogeneity of hollow ducts
-
摘要: 为了提高空心导管激光二极管(LD)抽运耦合系统的性能,采用理论分析和ZEMAX仿真模拟的方法研究了LD阵列封装误差对空心导管抽运耦合系统均匀性的影响.研究发现,当LD阵列中子光束经过空心导管后分割和叠加次数越多时,光束指向误差对空心导管的均匀性影响越小.在此基础上提出了空心导管LD抽运耦合系统的设计中对LD阵列光束准直的原则.结果表明,根据实际情况决定LD阵列中快慢轴方向准直后发散角的大小,以保证快慢轴方向的光束经过空心导管后能够有适当的反射和叠加次数,从而实现较高的耦合效率和抗LD阵列封装误差影响的能力.该研究可用于指导该类空心导管LD抽运耦合系统的设计.Abstract: In order to improve the performance of a hollow duct pumping system,how assembling error of a laser diode(LD) array affects the homogeneity of hollow ducts was studied by means of theoretical analysis and ZEMAX simulation.The result shows that the more each beamlet in a LD array is segmented,the less homogeneity is affected by beam direction error in LD array.Based on the above,collimating principle of LD beam in a hollow duct pumping system was proposed.That is,the collimated divergence of a LD array in fast and slow direction should be in a certain value to make sure that each beamlet can reflect several times in both directions.This can help to get a high coupling efficiency and make it insensitive to assembling error in LD array.This research is valuable for designing such kind of LD pumping systems.
-
Keywords:
- laser technique /
- laser diode /
- hollow duct /
- pumping /
- assembling error
-
-
[1] WANG Y,CHEN P F,ZHAN P.Error analysis of light beam with a cylindrical lens as the beam collimator in end pumping scheme[J].Laser Technology,2007,31 (5):507-510 (in Chinese).
[2] GAO H Y,FU R L,CHEN D Sh,et al.Design of hollow duct as coupling system in solid-state laser end-pumped by LDA[J].Journal of Optoelectronics · Laser,2005,16(5):541-544(in Chinese).
[3] BEACH R J,HONEA E C,BIBEAU C,et al.Hollow lens duct:US,6160934[P].2000-12-12.
[4] AMINPOUR H,ASL I M,SABBAGHZADEH J,et al.Simulation and design of applied hollow-duct used for side-pumped cutting-edged of high power disk laser[J].Optics Communications,2010,283(23):4727-4732.
[5] BAYRAMIAN A,BEACH R,BIBEAU C,et al.FY96-98 summary report Mercury:next generation laser for high energy density physics[R].Livermore,USA:Lawrence Livermore National Laboraory,2000:19-27.
[6] DENG Q H,PENG H Sh,SUI Zh,et al.Coupling method for laserdiode-array end-pumped solid-state amplifiers[J].Applied Optics,2008,47 (31):5908-5915.
[7] DENG Q H,PENG H Sh,SUI Zh,et al.Simulation on a new coupling method of la ser diode array end-pumped large-aperture amplifiers[J].Acta Physica Sinica,2008,57(10):6340-6347(in Chinese).
[8] DUAN W T,JIANG D B,JIANG X J,et al.High power laser diode arrays end-pumped efficient coupling system[J].Chinese Journal of Lasers,2009,36(1):51-55(in Chinese).
[9] BACHMANN F,LOOSEN P,POPRAWE R.High power diode lasers technology and applications[M].New York:Springer,2007:75-117.
[10] JIA W,HU Y M,LI M Zh,et al.Simulation and design of hollow lens duct as a new kind of coupling system for high power laser diode arrays[J].Chinese Journal of Lasers,2004,31 (8):939-942 (in Chinese).
