Application of off-axis parabolic mirrors in temperature sensor calibration systems
-
摘要: 为了改善温度传感器动态校准系统中的晶体透镜对激光束的聚焦效果,使用离轴90°抛物面镜代替晶体透镜对系统进行了改造,通过几何光学方法,对离轴90°抛物面镜应用于激光聚焦光路时的光轴的角度失准对聚焦光斑造成的影响进行了分析,并利用改进后的系统对CHAL-010型热电偶进行时间常数测试和动态校准实验,得到了CHAL-010型热电偶在温度阶跃为242℃左右时的时间常数值,完成了该热电偶的动态校准.结果表明,采用离轴90°抛物面镜代替温度传感器动态校准系统中的晶体透镜能达到温度传感器动态校准的目的.Abstract: In order to improve focusing effect of the crystalline lens on the laser beam in a temperature sensor dynamic calibration system,a 90° off-axis parabolic mirror was used instead of the crystalline lens.The influence of the misalignment angle of the 90° off-axis parabolic mirror on the focused laser spot was studied according to geometrical optics.Utilizing the improved system,the CHAL-010-type thermocouple' s time constant at step temperature around 242℃ was tested and the dynamic calibration experiment was carried out.The results show that the new system reconstructed with the 90° off-axis parabolic mirror can fulfill the dynamic calibration of temperature sensors.
-
-
[1] CHEN W L,ZHOU H Ch,HAO X J,et al.Test analysis of the laser's response time in the transient dynamic calibration system of high-temperature transducer[J].Metrology & Measurement Technique,2005,32(7):16-17.
[2] AN L Sh.Journal of applied optics[M].Beijing:Beijing Institute of Technology Press,2007:14-73 (in Chinese).
[3] TANG X H.High power transverse flow CO2 laser and its applications[M].Wuhan:Huazhong University of Science & Technology Press,2008:172-174(in Chinese).
[4] SHI H B,CHENG Zh G,XU G L,et al.Study on focusing spot characteristic by off-axis parabolic mirror[J].Chinese Journal of Lasers,2000,27(10):880-884(in Chinese).
[5] TAO X Y,ZHOU H R,L(U) B D.Study on beam propagation characteristics by means of the Fourier series expansion[J].Laser Technology,2003,27(2):150-152(in Chinese).
[6] HAN R D,SHEN X J,WANG L.Transmission characteristics of flattened Gaussian beams passing through a misaligned optical system[J].Laser Technology,2010,34(5):704-706(in Chinese).
[7] XIAO R S,MEI H H,ZUO T C.The role of laser beam performance in laser materials processing[J].Journal of Beijing Polytechnic University,1996,22(3):43-45(in Chinese).
[8] LI B,LI Y D,CHEN J Q,et al.The influence of thermal-lens effect on laser beam focusing[J].Optical Instruments,2007,29(6):44-48(in Chinese).
[9] LUO X,CHEN P F,WANG Y.Analysis of 90°off-axis parabolic mirror focal spot characteristic[J].Acta Optica Sinica,2009,29(3):683-686(in Chinese).
[10] REN L,HUANG F L.Analysis and prospect on studying dynamic characteristics of temperature sensors[J].Chinese Journal of Science Instrument,2009,38(2):50-51 (in Chinese).
[11] HAN D S,HAO X J,WANG G.The application of SR830 lock-in amplifier the transient temperature sensor dynamic test[J].China Instrumentation,2007,27(12):32-34(in Chinese).
[12] CHEN W L,HAO X J.The optic design of the surface temperature sensor's traceable dynamic calibration system[J].Sensor World,2006,12 (2):12-15(in Chinese).
