Study on machinability for laser-assisted machining of hydraulic carbon-graphite seal rings
-
摘要: 为了实现液压碳石墨密封环的高效车削加工,采用激光辅助加工方法,进行了碳石墨密封环材料的激光辅助车削加工研究.考虑到碳石墨密封环材料具有高强度、高硬度等特点,利用激光束对工件进行局部加热,以提高加工效率、减小切削力和刀具磨损.针对碳石墨M104密封环的车削加工过程,进行了常规切削和激光辅助切削的对比实验研究.设计了激光辅助加工的实验流程,并进行了工艺参量的合理选择,得到了较高的切削效率.结果表明,激光辅助切削的主切削力和径向力分别比常规切削下降了23.5%和19.9%;激光辅助切削的切削区温度分布与常规切削相近;刀具磨损和破损的程度较小,能获得较好的表面加工质量.Abstract: To perform high efficient turning of hydraulic carbon-graphite seal rings,the laser-assisted machining of the material of carbon-graphite seal ring was conducted using laser pre-heating.The material of carbon-graphite seal rings has the characteristics of high strength and high hardness,and is typical non-metallic difficult-to-machine material.The laser-assisted machining heats the workpiece using laser beam,improving machining efficiency as well as reducing cutting force and tool wear.The turning process of carbon-graphite M104 seal ring was focused on,and the conventional machining was compared with the laser-assisted machining.The experimental process of laser-assisted machining was designed and reasonable process parameters were selected.A high cutting efficiency was obtained.The main cutting force and radial force decreased by 23.5% and 19.9% compared with conventional machining.The temperature distribution in the cutting zone of laser-assisted machining is similar to conventional machining.The laser-assisted machining has less tool wear and can get a better surface quality.
-
-
[1] LI J.Laser assisting heating cutting technology[J].Machinery Design and Manufacture,2009,49(12):174-176(in Chinese).
[2] JIANG R B,LIAN L C,YAN C.Analysis of the performance in the turning engineering ceramics by laser heating[J].Manufacturing Technology and Machine Tool,2010,38(9):84-87(in Chinese).
[3] CHANGA C W,KUO C P.An investigation of laser-assisted machining of Al2O3 ceramics planning[J].International Journal of Machine Tools & Manufacture,2007,47(3/4):452-461.
[4] BRECHER C,ROSEN C,EMONTS M.Laser-assisted milling of advanced materials[J].Physics Procedia,2010,5(2):259-272.
[5] WAN Y,AI X,LIU Z Q,et al.Tool wear and fracutre in high speed milling aluminum alloy 7050-T7451[J].Chinese Journal of Mechanical Engineering,2007,43(4):103-108(in Chinese).
[6] MELKOTE S,KUMAR M,HASHIMOTO F,et al.Laser assisted micro-milling of hard-to-machine materials[J].CIRP Annals-Manufacturing Technology,2009,58(1):45-48.
[7] JEON Y,PFEFFERKORN F.Effect of laser preheating the workpiece on micro end milling of metals[J].Journal of Manufacturing Science and Engineering,2008,130(1):1-9.
[8] WANG Y,LI Y H,LIAO C R,et al.Study on arts and crafts of stainless steel micro-cantilever prepared with femtosecond laser[J].Laser Technology,2010.34(3):347-347(in Chinese).
[9] PFEFFERKORN F,LEI S,JEON Y,et al.A metric for defining the energy efficiency of thermally assisted machining[J].International Journal of Machine Tools and Manufacture,2009,49(5):357-365.
[10] SINGH R,MELKOTE S.Laser-assisted mechanical micromachining[M].London:Springer,2008:10-11.
